Zeo Prep Filtration Media

Zeo Prep Water Filtration Systems


Zeo Prep Filtration Media System Features:

• Cation Exchange Capacity: 1.83 m.e./g
• pH Stability: 3-10
• Specific Surface Area: 1357 yd2/oz.
• Bulk Density: 45-80 lb/ft3
• Pore Size: 4.0 Δ
• Pore Volume: 15%
• Thermal Stability: 1202° F

Zeo Prep

How the Zeo Prep System works:

• Filters down to 5 microns
• Excellent for removing suspended iron, manganese and turbidity
• Removes dissolved iron, hardness and manganese through ion exchange
• Regenerates with salt brine
• Produced by Mother Nature in a crystalline form, ZeoPrepTM filters solids as no other media can
• Zeo Prep’s ion exchange properties make it a dual purpose option for problem water
• Tested and approved by the Water Quality Association

Filtration Options for Removing Nature’s Contaminants

ACTIVATED CARBON – Used for taste, odor, chlorine and organics removal including VOCs. The 12 x 40 mesh size traps particles of 30 micron and larger.

CENTAUR NDS 12X40 GRANULAR ACTIVATED CARBON – A high grade catalytic carbon excellent for removing chloramines and hydrogen sulfide from potable waters.

NEUTRALIZING CRUSHED MARBLE – A sacrificial media that dissolves in acidic water to create a neutral water. This process adds some hardness to the water. Crushed marble, a mined material, is used in it’s natural state.

PYROLOX – A naturally mined ore, Pyrolox is a mineral form of manganese dioxide used in reducing hydrogen sulfide, iron and manganese.

FILTER-AG – A lightweight, silica, crystalline quartz media with excellent filtering capability, requiring lower backwash flow rates.

FILTER-AG PLUS – A clinoptilolite natural media with a large surface area and microporous structure used for the reduction of suspended matter.

KDF – A bi-metal copper and zinc material used for iron and hydrogen sulfide removal. KDF can control bacteria, algae and fungus growth.

BIRM – A lightweight, catalytic filter media used for removing iron and manganese via oxidation. The oxidized iron or manganese is then filtered. Birm has an inert core coated with manganese dioxide.

MANGANESE GREENSAND – A glutonite greensand that is a catalytic material for the removal of iron, manganese and hydrogen sulfide. The media is intermittently regenerated with potassium permanganate or continuously with chlorine or a chlorine and potassium permanganate mixture.

MULTI-MEDIA – Multi-media is reverse graded layers of filter medias. The layered process allows for higher flow rates plus filtration down to 10 micron-sized particles. Works well for sediment, turbidity and red water iron.

ZEO PREP – Filters down to 5 microns. Excellent for removing suspended iron, manganese and turbidity. Removes dissolved iron, hardness and manganese through ion exchange. Can be regenerated with salt brine. Zeo Prep filters solids like nothing else. Zeo Prep’s ion exchange properties make it a dual purpose option for problem water.

printable brochure
